FX Series (Fixed Power)

FX-I Rimfire 4x28 Fine Duplex

Part #
58680

Leupold® Rimfire riflescopes are built and tested to the same high standards as all Gold Ring® riflescopes. The FX™-I Rimfire 4x28mm gives you clear four-power magnification that's adjusted to account for parallax out to 60-yards.

matte finish
Fine Duplex Reticle info
$299.99

Leupold® Rimfire riflescopes are built and tested to the same high standards as all Gold Ring® riflescopes. The FX™-I Rimfire 4x28mm gives you clear four-power magnification that's adjusted to account for parallax out to 60-yards.

Featuring Leupold's Advanced Optical System, the FX-I Rimfire offers tried and true light transmission, best in class glare reduction in harsh light, and the resolution and clarity that recreational sportsmen and sportswomen demand.

The FX™-I Rimfire is 100% waterproof and fogproof. And like all Leupold riflescopes, it's designed, machined, and assembled in the USA and guaranteed for life.

Features
Leupold’s Advanced Optical System offers tried and true light transmission for extended glassing sessions, best in class glare reduction in harsh light, and the resolution and clarity that recreational sportsmen and sportswomen demand.
In Second Focal Plane (rear focal plane) scopes, the reticle stays the same size while the target grows and shrinks when you adjust the magnification. These reticles are ideal for lowlight hunting situations and in scopes that don't utilize hash marks for range estimation.
Leupold pioneered modern waterproof and fogproof technology using advanced internal gasses and sealing methods that withstand extreme temperatures, elevation changes, and shocks, so the internals of the optics stay moisture free and crystal clear for life.
Leupold’s Advanced Optical System offers tried and true light transmission for extended glassing sessions, best in class glare reduction in harsh light, and the resolution and clarity that recreational sportsmen and sportswomen demand.
In Second Focal Plane (rear focal plane) scopes, the reticle stays the same size while the target grows and shrinks when you adjust the magnification. These reticles are ideal for lowlight hunting situations and in scopes that don't utilize hash marks for range estimation.
Leupold pioneered modern waterproof and fogproof technology using advanced internal gasses and sealing methods that withstand extreme temperatures, elevation changes, and shocks, so the internals of the optics stay moisture free and crystal clear for life.
Specifications
More Information
UPC 00030317586805
Finish Matte
Adjustable Objective No
Side Focus No
Elevation Adjustment Type Microfriction
Zero Stop No
Locking Dial No
Zero Lock Dial No
Revolution Indicator No
Rezero Type Resettable Index Ring
Windage Adjustment Type Microfriction
Custom Dial System (CDS) No
Custom Dial Compatible No
BDC Dial Included No
Reticle Fine Duplex
Illuminated No
Nightvision Compatible Illumination No
Daylight Bright Illumination No
Motion Sensor Technology (MST) No
Electronic Reticle Level No
Guard-ion Lens Coating No
Weight (oz) 7.5
Elevation Adjustment Range (MOA) 80
Elevation Adjustment Range (MIL) 23
Elevation Adjustment Range (cm @ 100m) 233
Elevation Adjustment Per Revolution 15 MOA
Elevation Dial Travel Limit Total Scope Travel
Windage Adjustment Range (MOA) 80
Windage Adjustment Range (MIL) 23
Windage Adjustment Range (cm @ 100m) 233
Windage Adjustment Per Revolution 15 MOA
Magnification Min 4
Objective Lens Diameter (mm) 28
Linear FOV Low Mag (ft@100yds) 25.5
Angular FOV Low Mag (Degrees) 4.9
Eye Relief Low Mag (in) 4.5
Fixed Parallax-Free Distance (yd) 60
Dimensions
A Total Length (in) - A 9.2
B Total Mounting Space (in) - B 4.8
C Front Mounting Space (in) - C 1.4
D Rear Mounting Space (in) - D 2.2
E Eyepiece Length (in) - E 2.3
F Objective Length (in) - F 2.2
G Objective Diameter (in) - G 1.4
H Eyepiece Diameter (in) - H 1.4
K Maintube Diameter (mm/in) - K 1 Inch

Detailed reticle info

Fine Duplex

Download PDF
  • Based on our Duplex® style design
  • Thinner posts and crosshairs
  • Better for precision shots
  • Makes small target acquisition easier
  • Rear (second) focal plane
