DeltaPoint Micro

DeltaPoint Micro (S&W M&P)

Part #
179570

The DeltaPoint Micro™ is a fully enclosed, low-profile red dot sight designed specifically
for concealed carry and personal defense.Mounted directly to the rear sight dovetail, the DeltaPoint Micro sits at the same height as factory iron sights and aligns the red dot with the front sight, giving you faster target acquisition and improved accuracy.

matte finish
3 MOA Dot Reticle info
$399.99

The DeltaPoint Micro™ is a fully enclosed, low-profile red dot sight designed specifically for concealed carry and personal defense. Until now, there hasn’t been a compact red dot sight suited for pistols with smaller frames and lower sight profiles, but the DeltaPoint Micro changes the game. Mounted directly to the rear sight dovetail, the DeltaPoint Micro sits at the same height as factory iron sights and aligns the red dot with the front sight, giving you faster target acquisition and improved accuracy. And with eight levels of illumination, you can easily adjust the brightness of your red dot to match current conditions. If you need a rugged and reliable red dot for a conceal carry pistol but don’t want to deal with replacing factory sights or complicated mounting systems, then the DeltaPoint Micro is for you. Current
models fit Glock® and Smith & Wesson® M&P® handguns only.

Features
Leupold pioneered modern waterproof and fogproof technology using advanced internal gasses and sealing methods that withstand extreme temperatures, elevation changes, and shocks, so the internals of the optics stay moisture free and crystal clear for life.
Leupold pioneered modern waterproof and fogproof technology using advanced internal gasses and sealing methods that withstand extreme temperatures, elevation changes, and shocks, so the internals of the optics stay moisture free and crystal clear for life.
Specifications
More Information
UPC 00030317026288
Finish Matte
Adjustable Objective No
Side Focus No
Elevation Adjustment Type Microfriction
Zero Stop No
Locking Dial No
Zero Lock Dial No
Revolution Indicator No
Windage Adjustment Type Microfriction
Custom Dial System (CDS) No
Custom Dial Compatible No
BDC Dial Included No
Reticle Type MOA Scale
Reticle 3.0 MOA Dot
Light Management System Twilight Max
Battery Type CR1632
Switch Type Push Button
Illuminated Yes
Nightvision Compatible Illumination Yes
Daylight Bright Illumination No
Motion Sensor Technology (MST) Yes
Electronic Reticle Level No
Display No
5:1 Zoom Ratio No
Guard-ion Lens Coating No
Lightweight Aluminum Housing No
Weight (oz) 1.1
Elevation Adjustment Range (MOA) 100
Elevation Adjustment Range (MIL) 29
Elevation Adjustment Per Revolution 18 MOA
Elevation Dial Travel Limit Total Scope Travel
Windage Adjustment Range (MOA) 180
Windage Adjustment Range (MIL) 52
Windage Adjustment Per Revolution 36 MOA
Eye Relief Low Mag (in) Unlimited
Battery Life (hr), Low Intensity 100000
Battery Life (hr), Medium Intensity 30000
Battery Life (hr), High Intensity 500
Number of Illum Settings 8
Dimensions
A Total Length (in) - A 2.25
F Objective Length (in) - F .35
G Objective Diameter (in) - G .35
H Eyepiece Diameter (in) - H .35

Detailed reticle info

3 MOA Dot

3 MOA Dot
