BLEM VX-3HD 4.5-14x50 (1 inch) CDS-ZL Duplex
Specifications
More Information
| BDC Dial Included |
No |
| Custom Dial System (CDS) |
Yes |
| Custom BDC Dial Compatible |
Yes |
| Daylight Bright Illumination |
No |
| Elevation Adjustment Type |
CDS-ZL |
| Electronic Reticle Level |
No |
| Illuminated Reticle |
No |
| Light Management System |
Elite Optical System |
| Locking Dial |
Yes |
| Motion Sensor Technology (MST) |
No |
| Nightvision Compatible Illumination |
No |
| Reticle Focal Plane |
Second Focal Plane |
| Revolution Indicator |
No |
| Reticle |
Duplex |
| Rezero Type |
Set Screw |
| Adjustable Objective |
No |
| Precision Side Focus |
No |
| Windage Adjustment Type |
Finger Click |
| Weight (oz) |
16.9 |
| Elevation Adjustment Value per Click |
1/4MOA |
| Elevation Adjustment Range (MOA) |
75 |
| Elevation Adjustment Range (MIL) |
21.8 |
| Elevation Adjustment Range (cm @ 100m) |
218.2 |
| Elevation Adjustment Per Revolution |
15 MOA |
| Elevation Dial Travel Limit |
14.5MOA |
| Windage Adjustment Value per Click |
1/4MOA |
| Windage Adjustment Range (MOA) |
75 |
| Windage Adjustment Range (MIL) |
21.8 |
| Windage Adjustment Range (cm @ 100m) |
218.2 |
| Windage Adjustment Per Revolution |
15 MOA |
| Magnification Max |
14 |
| Magnification Min |
4.5 |
| Objective Lens Diameter (mm) |
50 |
| Linear FOV Low Mag (ft@100yds) |
20.5 |
| Linear FOV High Mag (ft@100yds) |
7.6 |
| Angular FOV Low Mag (Degrees) |
3.9 |
| Angular FOV High Mag (Degrees) |
1.5 |
| Eye Relief Low Mag (in) |
4.4 |
| Eye Relief High Mag (in) |
3.6 |
| Fixed Parallax-Free Distance (yd) |
150 |
Dimensions
|
A
Total Length (in) - A |
12.29 |
|
B
Total Mounting Space (in) - B |
5.3 |
|
C
Front Mounting Space (in) - C |
1.59 |
|
D
Rear Mounting Space (in) - D |
2.48 |
|
E
Eyepiece Length (in) - E |
3.08 |
|
F
Objective Length (in) - F |
3.91 |
|
G
Objective Diameter (in) - G |
2.3 |
|
H
Eyepiece Diameter (in) - H |
1.56 |
|
K
Maintube Diameter (mm/in) - K |
1 Inch |
